A Technical Deep Dive into the HX180 Automatic Book Sewing Machine

For technical directors and procurement officers, the details matter. The HX180 Automatic Book Sewing Machine by HXCP is a precision instrument designed for modern post-press needs. Let's take a closer look at the technical specifications that make this machine a leader in its class.

HX180 Automatic Book Sewing Machine

Performance Parameters The HX180 Automatic Book Sewing Machine is built for speed and precision. It operates at a maximum speed of 180 cycles/minute, powered by a 4.2kW motor system. It supports standard voltages of 380V/220V (50/60Hz, 3ph), ensuring compatibility with most industrial power grids globally.

Stitching and Handling

• Stitches: The machine utilizes 10 stitches with a fixed length of 19mm, providing a tight, secure bind for various signature thicknesses.

• Opening Head: Features a 4-4-LAP opening head configuration.

• Paper Handling: Capable of sewing signatures with a thickness between 0.25mm and 4mm, offering versatility for different paper weights.

Dimensions and Installation Despite its heavy-duty weight of 2500kg, the machine maintains a relatively compact footprint of 2525×1545×1350mm (L×W×H). It requires a compressed air supply of 500L/min @6bar, standard for industrial finishing equipment.

The HX180 Automatic Book Sewing Machine combines heavy-duty industrial engineering with precise control, making it the technical choice for serious bookbinders.
